Small electrical cabinets for industrial, civil and service sector up to 250 A

(IP30 – IP55, from FORM 1 to FORM 2).

Better access from the front as a result of an increase in width and an easier disassembly of the frames independently fixed.

Same internal accessories available for Slim, Easy 630 and Compact series thanks to the ModularDIN™ system that enables rapidity and precision of modular circuit breakers assembly.

MAIN CHARACTERISTICS

Monoblock structure made of welded sheet with a thickness of 1,2 mm.
Degree of protection from IP31 (open version) to IP55 with blind door or transparent door with toughened glass.
Top and bottom completely removable.
Possibility of vertical connection and frame for flush mounting.
Installation of circuit breakers of all leading manufacturers (ABB, Schneider, Siemens, etc.).
Epoxy powder coating after phosphating in RAL 7035 B (other colours on request).
On request, stainless steel small cabinet.
Patented and certified earth connection system.
Full range of internal finishing accessories to provide solutions for any requirement.

ADVANTAGES

Fully assembled structure.
Fast plate assembly/disassembly.
Possibility to perform wiring directly on the plate. Mounting plate prepared for DIN supports and electrical devices supports.
Universal certified framework designed to install all electrical equipment available on the market, with the same wiring method regardless of the equipment brand used.
Accessories for supporting horizontal or vertical cable trays and terminal blocks included in the supply.
Compatible and interchangeable accessories among the Quick, Slim, Easy 630, and Compact series products.
Stocked warehouse for Express delivery.
Maximum flexibility of use thanks to the possibility of using glass door, blind door, inner door and swivel frame.
Possibility of designing the structure with Fast-One configurator and calculating the overtemperature according to regulations in force.

CUSTOMISATION SERVICES

Custom painting available on request with fast turnaround times.
Customised drillings on request.
Positioning of certified busbar systems.
Support/door kit designed for any molded case circuit breaker.

TYPOLOGY

QV – Small cabinet

Monoblock structure made of welded sheet with a thickness of 1,2 mm.

QVM – Small cabinet with cable housing

Monoblock structure made of welded sheet with a thickness of 1,2 mm, with cable housing for cables, terminal block or busbar system.

QT – Cabinet with blind door

Monoblock structure made of welded sheet with a thickness of 1,2 mm and blind door.

QD – Double section cabinet

Thanks to this system it is possible to open the frontal part of the small cabinet and get directly to the wiring plate.
Allows front opening for direct access to the wiring plate.
