A new series of electrical cabinets designed to offer the maximum accessibility for both wiring and maintenance.
Complete modularity of the cabinet separated from the cable housing with the possibility of removing the frontal part. Same internal accessories available for Quick, Easy 630 and Compact series thanks to the ModularDIN™ system that enables rapidity and precision of modular circuit breakers assembly.
MAIN CHARACTERISTICS
- Assembled structure made of sheet with a thickness of 1,5 mm.
- Degree of protection IP30 with transparent door with toughened glass.
- Top or bottom plates for wires management.
- Possibility of vertical connection.
- Installation of circuit breakers of all leading manufacturers (ABB, Schneider, Siemens, etc.).
- Epoxy powder coating after phosphating in RAL 7035 B (other colours on request).
- Stainless steel cabinet available on request.
- Patented and certified earth connection system.
- Full range of internal finishing accessories to provide solutions for any requirement.
ADVANTAGES
- Fully assembled structure.
- Speed of disassembly/assembly of front uprights for wiring or on-site maintenance.
- Universal certified framework designed to install all electrical equipment available on the market, with the same wiring method regardless of the equipment brand used.
- Accessories for supporting horizontal or vertical cable trays and terminal blocks included in the supply.
- Compatible and interchangeable accessories among the Quick, Slim, Easy 630, and Compact series products.
- Stocked warehouse for Express delivery.
- Possibility of designing the structure with the configurator Fast-One.
CUSTOMISATION SERVICES
- Custom painting available on request with fast turnaround times.
- Customised drillings on request.
- Support/door kit designed for any molded case circuit breaker.
- Positioning of certified busbar systems.
TYPOLOGY
QS – Cabinet
Assembled structure made of sheet with a thickness of 1,5 mm.
QP – Cabinet with internal cable housing
Monoblock structure made of welded sheet with a thickness of 1,5 mm, with internal cable housing for cables, terminal block or busbar system.
QR – Cabinet with cable housing
Assembled structure made of sheet with a thickness of 1,5 mm and with cable housing for cables, terminal block or busbar system.
QSV – Cable housing
Monoblock structure made of welded sheet with a thickness of 1,5 mm, combinable with the cabinet.
IP30 frame
It is possible to replace the glass door with the IP30 frame (open version).
